Product advantages:
The product is equipped with durable contacts, which have the dual advantages of low resistance signal transmission and high mechanical durability. It is suitable for key functional scenarios such as temperature control triggering and cabin door interlocking of water heaters, and can operate continuously and stably for a long time, ensuring that the water heater accurately responds to water temperature adjustment instructions and guarantees power-off protection when the cabin door is not closed.
ZINGEAR micro switch, safeguarding the safety of home hot water use with exquisite quality.
Key Features:
·Waterproof and dustproof (IP67) design
·Small in size and tight in grip
·Having global safety certification
·Long lifespan, high reliability
·Equipped with various forms of operating handles
·The types of wire connectors are complete
·Widely used in fields such as automotive control, home appliance control, industrial control, etc
·Various installation dimensions meet different installation requirements
Technical parameters：
Operating Voltage | 250VAC |
Rated Current | 16A |
Contact Resistance | 100mΩ Max. |
Insulation Resistance | 100mΩ Min. |
Contact Form | Single Knife Double Throw (SPDT) |
Operating Force (OF) | customizable |
Operating Temperature | -25℃～+125℃ |
Contact Material | customizable |
Electrical Life | 50,000次 Min. |
Mechanical Life | 100,000次 Min. |
Protection Class | IP40 |
Terminal & Lever | Simulated roller handle |
Outline | basic type |
Withstand Voltage | 500 VAC (50~60HZ) leakage current<10mA --Between terminals. 1000 VAC (50~60HZ) current<10mA --Between terminals and non current carrying metal components --Terminal and shell |
Drawings：
